TECK Concealed Flush Valve for 1-1/2" Back Inlet Toilets

This quiet action, Teck concealed diaphragm flush valve is designed for use with freestanding 1-1/2" back inlet toilet fixtures. The unit features a vandal-resistant metal 5/8" diameter "non-hold open" push-button actuator, vandal-resistant handle control that can easily be located and installed anywhere within 20 feet of the flush valve, adjustable inlet/valve outlet centers, a vacuum breaker, a 1" FIP/Copper sweat inlet adaptor, and a field-adjustable flush rate of 1.27 to 6.6 gallons per flush (factory set to 1.6 gpf). Comes with a wall and spud flange and a concealed spud nut.

• Adjustable 4.31" to 5.19" inlet/valve outlet centers
• Chloramine-resistant diaphragm attached to guide with metal retainer
• Renewable seat
• Pressure loss check angle stop with wheel handle
• Polished chrome-plated finish on exposed trim
• Installs on all walls up to 12.5" thick
